5000 Series
Standard Indicators
5000 Series Indicators Offer Multiple Features and Easy Configuration:
To meet different operational needs, the 5000 Series includes a suite of configurable software:
• Counting mode for packaging and inventory control, enabling counting into a container or out of a container for bulk
operations. Supports a maximum displayed counting resolution to 1:300,000 (minimum APW equal to 0.1d), selectable
auto-optimization of average piece weight (APW). APW data can be displayed at any time by a quick key press.
• Percent Weighing mode for formulation and mixing applications, with display of reference weight with a quick key press.
• Dynamic/Animal Weighing with selectable weigh times from 0-60 seconds
• Checkweighing function for packaging and weight checking, with display of results using LCD display and red/yellow/
green LEDs. Audible beeper can be configured to prompt when weight is within range, under, over, or under/ over
range. Target weight values can be displayed at any time using a quick key press.
• Display Hold mode for weighing large packages holds last stable weight on display until cleared
• The 5000 Series weighs in one or more user-selectable units: kg, g, lb, oz, lb:oz (decimal), metric tonnes and
user-definable custom unit
• Supports GMP/GLP data output with date, time user ID, project ID and scale ID. The 5000 Series features selectable
print options for data and print format
• To limit operator access to functions, the 5000 Series offers both software lockouts for menu items as well as individual
key functions.
Options and Accessories
Interface Options
OHAUS Number
AC Relay Kit, T51P/T51XW .....................................................80500720
DC Relay Kit, T51P/T51XW .....................................................80500727
RS485/422 Interface Kit, T51P/T51XW ...................................80500731
RS232 Interface Kit, T51P/T51XW ..........................................80500733
Foot Switch .............................................................................71173378
Power Options
Rechargeable Battery Kit, T51P/T51XW ..................................80500729
Mounting Accessories
Wall Mount Kit, T51P ..............................................................72200227
Wall Mount Kit, T51XW ..........................................................80500735
Base Mount Kit, T51P .............................................................80500722
Column Mount Kit, 35cm, painted, T51 ..................................80500723
Column Mount Kit, 68cm, painted, T51 ..................................80500724
Column Mount Kit, 35cm, stainless steel, T51 .......................80500725
Mounting Accessories (continued) OHAUS Number
Column Mount Kit, 68cm, stainless steel, T51 .......................80500726
Compatible with all existing columns for Champs and CD/CW11/
CD31/33/CKW indicators
Other Accessories
Compact Dot Matrix Impact Printer ........................................80252042
Compact Thermal Printer ........................................................80251992
OHAUS Collect Software .........................................................80500746
TAL Software WinWedge ........................................................SW12W
Paper for Printer, 80252042 (1 roll) .......................................80251932
Ribbon for Printer, 80252042 .................................................80251933
RS232 Cable & Adapter, 80252042 Printer to T51XW ...........80252574
RS232 Cable, PC 9 Pin to T51XW ..........................................80500552
RS232 Cable, PC 25-pin to T51XW ........................................80500553
RS232 Cable & Adapter, 80252042 Printer to T51P ...............80252571
RS232 Cable, PC 9-pin to T51P ..............................................80500525
RS232 Cable, PC 25-pin to T51P ............................................80500524
Outline Dimensions
313 mm
12.4 in
260 mm
10.2 in
168 mm
6.6 in
71 mm
2.8 in
224 mm
8.8 in
315 mm
12.4 in
262 mm
10.3 in
149 mm
5.86 in
76 mm
3.0 in
212 mm
8.3 in
T51XW Indicator T51P Indicator
