5

SPECIFICATIONS

Standards and Certifications

• CE

• FCC

• PCI 3.0

• PCI Power Management Specification 1.1

• RoHS

• WEEE
Ports

• (4) serial DB9 male connection

• Up to 460 kbps throughput (230 kbps effective rate)

• OxFord chipset

• Superset and backwards compatible with 16C550, 16C650, 16C750 and

16C850

• 128-byte deep FIFO per transmitter and receiver

• 128Rx and 128Tx interrupt and 128 flow control thresholds
Bus

• PCI 3.0 32-bit, 33 MHz

• Supports 32/64-bit PCI slot

• 5 / 3.3 V bus power
Physical

• Dimensions: 124 x 122 x 23 mm (4.9 x 4.8 x 0.9 in.)

• Cable length: 508 mm (20 in.)

• Weight: 65.2 g (2.3 oz.)
