INSTALLATION
1. Power off the system. Insert the PCI Card into an available PCI slot.
2. Power up the system, and insert the driver CD into your CD-ROM/DVD drive.
3. When Windows displays the Found New Hardware Wizard, click Next.
4. Select “Search for a suitable driver for my device (Recommended)” and click
Next.
5. On the next screen, check that “Specify a location” is the only option that is
selected, then click Next.
6. Enter “X:\” (or whatever letter corresponds to your CD-ROM/DVD drive) and
click “Browse.”
7. Specify a location; for example, “X:\ PCI IO\OXmPCI \Win_Driver_v7.0 \x86” for
a 32-bit operating system). Click OK.
8. When the wizard indicates that it has found a driver for the device, click Next,
then click Finish.
9. Repeat Step 3 – Step 8.
5 VDC Jumper Setting for each RS232 Port
• 5 VDC on Pin 9 of the DB9 connector = 5 V short
• Normal RI function on Pin 9 of the DB9 connector = RI short
VERIFYING INSTALLATION
1. Right-click on the desktop My Computer icon and select “Properties.” Click on
the Hardware tab, then click Device Manager.
2. Double-click “Multifunction adapters.” If there is no yellow “!” or “?” in front of
“OX16PCI954 PCI UARTs (unique bars)” or “OX16PCI95x PCI bridge,” continue
to the next step.
3. Double-click any of the four “PCI Communications Port (COM3–6)” listings. If
there is no yellow “!” or “?” in front of these, the driver has been successfully
installed.
