MC-SFP-10km
1310 nm Single-mode Transceiver, 10.5dB margin
Small Form Pluggable (SFP), 3.3 V
1.0625Gbd Fiber Channel/1.25 Gigabit Ethernet
TEC Opitx Solutions
Division of Lynn Electronics Corp.
154 Railroad Drive • Ivyland, PA. 18974
Receiver Electro-optical Characteristics
Vcc = 3.1 V to 3.5 V, T
A
= 0
°C to 70
°C
PARAMETER
SYMBOL
MIN
TYP.
MAX
UNITS
NOTE
Optical Input Power-maximum
P
IN
3
---
---
dBm
BER < 10
12
Optical Input Power-minimum
(Sensitivity)
P
IN
---
---
20
dBm
BER < 10
12
Operating Center Wavelength
C
1260
---
1610
nm
Optical Return Loss
ORL
12
---
---
dB
Receiver Electrical 3dB Upper
Cutoff Frequency
---
---
---
1500
MHz
Signal Detect-Asserted
P
A
---
---
20
dBm
Signal Detect-Deasserted
P
D
31
---
---
dBm
Stressed Receiver Sensitivity
---
---
14.4
dBm
Note 1, 2
Differential Output Voltage
V
DIFF
0.37
---
2.0
V
Data Output Rise, Fall Time
(20
80%)
T
r, f
---
---
0.35
ns
Receiver Loss of Signal Output
Voltage-Low
RX_LOS
L
0
---
0.5
V
Receiver Loss of Signal Output
Voltage-High
RX_LOS
H
2.4
---
V
CC
V
Receiver Loss of Signal Assert
Time (off to on)
t
A,RX_LOS
---
---
100
μs
Receiver Loss of Signal Assert
Time (on to off)
t
D,RX_LOS
---
---
100
μs
Note 1: Measured with conformance test signal at TP3 for BER = 10
12
at the eye center.
Note 2: Measured with a transmit signal having a 9 dB extinction ratio. If another extinction ratio is used, the Stressed receiver
sensitivity should be corrected for the extinction ratio penalty.
