Issue 3.1.B

Xedio Version 3.1 - User’s Manual – Xedio Playout Organizer

EVS Broadcast Equipment – January 2011

4.4 PLAYOUT EFFECTS

4.4.1 S

ETTING THE

TART

ODE

Three start modes are available:

CONTINUOUS: All items of the playlist will be automatically chained together.
STEP: The playlist will stop on the last frame of each item.

FREEZE ON IN: When an item has been played, the next one will be automatically
preloaded and the playout will pause on the first frame.

Note

One of these start modes is used as default. It can be changed in the
Tools > Options > Options menu. Please refer to section 6.2 ‘Default

Start Mode’ on page 23 for more information.

4.4.2 S

ETTING THE

RANSITION

FFECTS

If the Start mode is set to CONTINUOUS, a MIX transition effect can be executed
between two items. In the Effect column, select MIX and in the Effect duration

column, enter the duration of the effect.

4.4.3 B

ROADCASTING A

LAYLIST

When a playlist is ready to be played out to air, it needs to be connected to the
playout server (hardware) component.
In the Output field, select the hardware hosting the Playout server:
