main
CapaBiLities
DepenDaBiLity &
seCurity
the Xstorese is field-proven and reliable
in even the most extreme broadcasting
conditions. Hot-swappable redundant
power supplies ensure your content is
never lost, and cutting edge storage
architectures like fibre channel, sata,
and sas make the Xstorese the most
up-to-date storage server available.
aDVanCeD WorKFLoW
integration
automatic backup of clips with the
associated metadata is a standard feature
of the Xstorese. the Xstorese makes it
possible for users to recall clips to select
show content and build highlights.
the Xstorese also offers multi-format
edit and playback device support.
streamLines
proDuCtion
as near-line storage, the Xstorese frees
up Xt series servers, so your workflow
never slows down. the Xstorese can also
be used as online storage for the Xedio
Cleanedit workstation. media export via
gigabit ethernet quickens the pace of any
production exponentially.
FuLLy
sCaLaBLe
sCsi technology with up to 2.5tB,
raiD 5 protected, gives your workflow
extreme flexibility for any environment.
the Xstorese offers fibre channel storage
architecture for larger installations
needing high bandwidth, while sata
can be used for large capacity projects
with low bandwidth requirements.
the Xstorese is equipped with a compact
4ru enclosure with up to 10-24 hard
drive disks.
meDia management
& eDiting
FunCtionaLity
the Xstorese can host additional
eVs applications to offer a complete
production solution, including Xedio
Cleanedit media manager, which lists
all of the available media along with its
relevant metadata. the Xstorese offers
complete integration with Xedio Cleanedit
nLe, a multi-format non-linear editor
built for fast turnaround editing with
no rendering required. the Xstorese can
be used for the import and export
of mXF files to third-party editing
systems, p2 / XDCam cameras, and new
media formats.
the XStoreSE is a fully scalable and
flexible server for the storage of clips,
media, live feeds, and any content
originated from production servers
or nlE stations, for either short- or
long-term archiving. the world’s top
broadcasters consistently choose EvS
storage and gateway solutions for their
reliability, security, and expandability.
“We save time and money because we have direct access to content during production
for scripting or highlighting purposes. also, we can check that a sequence has
been synchronized even before it has finished. We no longer need to search through
recorded tapes during post production and we have more logging flexibility.”
Eduard ramo
mediamovil Facility Company, spain
tEchnicAl
speCiFiCations
pHysiCaL Dimensions - 19-inch enclosure 4ru - size (H x D x W) : 178 x 605 x 452mm / 7” x
23.8” x 17.8”
WeigHt - 40 kg / 88 lb (subject to slight variations due to options)
poWer requirement - Double-redundant aC power supply with pFC 2n+1 100-240V,
47-63Hz, 760W max.
enVironmentaL
ConDitions
- operating temperature range : 10° to 35°C (50° to 95°F)
- non operating temperature range : -40° to 70°C (40° to 158°F)
- operating / non operating Humidity range : 8-90% max.
non condensing
remoVaBLe storage - 1x removable drive bay compatible with eVs XFile disks
- 1x DVD+/-r;
sHareD storage - internal sas storage (up to 24 HDD max) : up to 12.6 tB raw capacity
raiD 5 with 1 hot spare disk
- internal sata storage (up to 10 HDD max) : up to 18 tB raw capacity
raiD 5 with 1 hot spare disk
- external sata storage array (3u with 14 HDD max) :
- up to 13 tB raw capacity per array - (raiD 6 with 1 hot spare disk)
- up to 78 tB raw capacity (raiD 6 with up to 3 hot spare disks)
Cpu - 2 x quad core processors
it interFaCes - ethernet : 2x gigabit ethernet (rJ-45 connectors)
- 1x Firewire ieee-1394 (1 front); 6x usB-2.0 (2 front - 4 back)
a/V netWorK - Xnet[2] 1.5gbps/540mbps connecting eVs Xt series servers
