Dunlop Manufacturing M135 - Manual (Page 4)

DUNLOP MANUFACTURING, INC. P.O. BOX 846 BENICIA, CA 94510 U.S.A.
TEL: 1-707-745-2722 FAX: 1-707-745-2658 WWW.JIMDUNLOP.COM
92503001862
SPECIFICATIONS
Input Impedance: 1 Megohm
Input Level: 2Vrms (+6dBV) max
Output Impedance: <1Kohm
Signal to Noise: CLOSED : 106dBV A weighted (Vref 1V RMS)
OPEN : HISS >100dBV A weighted (Vref 1V RMS)
MID >100dBV A weighted (Vref 1V RMS)
FULL >96dBV A weighted (Vref 1V RMS)
Frequency Response: BYPASS : 20Hz to 10Khz +0dB/-.1dB
NOISE CUT “OFF” (ALL MODES) : 20Hz to 20kHz ±1dB
NOISE CUT “ON”: HISS -3dB at 1kHz
-20dB at 15kHz
-25dB at 20kHz
MID -3dB at 500Hz
-30dB at 20kHz
FULL >-30dB at 60Hz
-15dB at 500Hz
-25dB at 20Hz
Power Draw: 15 Milliamps
Power Requirement: 9VDC adapter with 5.5mm x 2.1mm positive barrel
and negative center or standard 9 Volt battery
