GCB95 ORIGINAL CRy BABy
®
SPECIFICATIONS
Impedance
Input 800 kΩ
Output 10 kΩ
Resonant Frequency
Heel Down 350 Hz - 450 Hz
Toe Down 1.5 kHz - 2.5 kHz
Maximum Level
Input -8.0 dBV
Output +10 dBV
Maximum Gain
Heel Down +19.5 dB
Toe Down +19.0 dB
Signal to Noise Ratio *
Heel Down 98 dB
Toe Down 89 dB
Current Draw 900 µA
*A-weighted, OdBV = 1V
RMS
POWER
The Original Cry Baby ® can be powered
by one 9 volt battery (accessed via the
bottom of the pedal), a Dunlop ECB003
AC adapter (ECB003E in Europe) or a
Dunlop DCB10 DC Brick power supply.
SETUP INSTRUCTIONS
• Run a shielded instrument cable from your
guitar to the GCB95’s Instrument jack.
• Run another shielded instrument cable
from the GCB95’s Amplifier jack into
your amplifier input.
• Turn on the amplifier and begin playing.
• To turn the pedal on/off, push the toe of
the pedal down until you feel a “click.”
• By rocking your foot back and forth
on the pedal, you can instantaneously
change the effect that the Original Cry
Baby has on the tone of your instrument.
