POWER
The Kirk Hammett Signature Cry Baby ®
Wah Wah is powered by one 9-volt battery
(accessed via the bottom of the pedal),
an AC adapter such as the Dunlop
ECB003/ ECB003E, or a DC Brick ™
power supply.
SETUP INSTRUCTIONS
• Run a shielded instrument cable from your
guitar to the KH95’s INSTRUMENT jack.
• Run another shielded instrument cable
from the KH95’s AMPLIFIER jack into
your amplifier input.
• Turn on the amplifier and begin playing.
• To turn the pedal on/off, push the toe of
the pedal down until you feel a “click”.
• By rocking your foot back and forth on
the pedal, you can change the effect
that the Cry Baby has on the tone of
your instrument instantaneously.
SPECIFICATIONS
Impedance
Input 680 kΩ
Output 4.7 kΩ
Filter Parameter
Low Pass 300 Hz to 380 Hz
High Pass 1.4 kHz to 1.8 kHz
Maximum Level
Input -13.5 dBV
Output +6.5 dBV
Maximum Gain
Heel Down +17 dB at 300 Hz to 380 Hz
Toe Down +21 dB at 1.4 kHz to 1.8 kHz
Noise Floor *
Heel Down >95 dBV
Toe Down >89 dBV
Bypass Hardwire
Current Draw
4 mA
Power Suppy 9 volts DC
* OdBV=1V
RMS , A-weighted
KH95 KIRK HAMMETT CRy BABy
®
WAH WAH
