DIRECTIONS
• Run a cable from your guitar to the
Fuzz Face’s Input jack and run another
cable from the Fuzz Face’s Output jack
to your amplifier.
• Start with VOLUME and FUZZ controls
at 12 o’clock.
• Turn the effect on by depressing
the footswitch.
• Rotate VOLUME knob clockwise
to increase overall volume or
counterclockwise to decrease it.
• Rotate FUZZ knob clockwise to increase
the amount of fuzz or counterclockwise
to decrease it.
SAMPLE SETTINGS
SPECIFICATIONS
Input Impedance 10kΩ
Output Impedance
Max Volume 2kΩ
Mid Volume 50kΩ
Max Output -6dBV
Max Gain 45dB
Bypass True Hardwire
Current Draw 3.4mA
Power Requirement 9 volts DC
DESCRIPTION
• Built around the toneful BC108
silicon transistor
• Jimi’s Fuzz Face tone in a pedalboard-
friendly housing
• Limited edition finish featuring art
by legendary rock artist John
Van Hamersveld
POWER
The JHM1 Jimi Hendrix 70th Anniversary
Tribute Series Fuzz Face can be powered
by one 9 volt battery (accessed via the
bottom of the pedal), a Dunlop ECB003
AC adapter (ECB003E in Europe) or a
DC Brick ™ series power supply. .
CONTROLS
• VOLUME knob controls overall volume
of effect
• FUZZ knob controls amount of fuzz
• FOOTSWITCH toggles effect on/bypass
(indicated by blue LED)
VOODOO CHILD
(SLIGHT RETURN)
SPANISH CASTLE
MAGIC
VOLUME VOLUME FUZZ FUZZ
