6 Dune HD Smart D1 Quick Start Guide
A/V
Package Contents
1. Dune HD Smart D1 media player
2. Remote control (batteries may not
be included)
1
NOTE: Additional items (optional) may be included into the package, depending on player configuration,
region, and distributor.
Exterior
3. HDMI cable
4. AV cable
5. Power supply cord 6. External power supply
7. Quick start guide
Front view
1. On/off button
2. LED indicator
3. IR eye
4. SD card slot
5. Display
6. USB 2.0 host
7. Eject button (*)
* For controlling an external optical
drive (when connected)
1 2 3 4 5 6 7
4
2
3
5 7 6
Rear view
1. LAN and 2xUSB 2.0 host
2. Composite video and analog stereo audio
output
3. Component (Y/Pb/Pr) video output
4. HDMI 1.3
5. eSATA host
6. Optical digital audio output
7. USB Slave
8. Dedicated bus connector (I
2 C) (for future
connecting external devices)*
9. DC power 12V
10. Power switch
* Not for headphones or other A/V devices;
connecting headphones or other A/V devices may
damage your equipment
1 2 3 4 5 6 8 10 7 9
