Facilities
The facilities used for this testing were located at:
APSCO International
3700 Lane Road
Perry, Ohio 44081
APSCO International was chosen for it’s well qualified lead-free SMT and Wave
production lines and knowledgeable personnel. APSCO has been addressing RoHS
compliance since 2003.
Equipment
Equipment used for the Pb free tests was:
Screen Printer...MPM SP
Component Placement...MYDATA MY12
SMT Reflow Oven...Electrovert Omniflo-10
Inspection...Ersa scope
Xray...Nicolet NXR 1510 System
The collection of the time/temperature data was done with a Datapaq Data Logger
and processed using the Datapaq Insight Reflow Tracker v1.40 software.
Additional visual inspection was made using Leica StereoZoom SZ-4
microscopes with 10X eyepieces mounted.
