AP1100
Cable Material
Connector Style Numbers:
Socket Without Tab:
Style No.: 39001
Socket With Tab Key:
Style No.: 39002
DIP:
Style No.: 39007
DRB:
Style No.: 39023
SRB:
Style No.: 39033
SRS:
Style No.: 39035
Left Down
LN
Right Down
RN
Stripe Up
SP
Standard Assembly Styles
Left Down
LN
Right Open
RO
Stripe Up
SP
Left Down
LN
Right Open
RO
Stripe Down
SN
Left Down
LN
Right Up
RP
Stripe Up
SP
Left Down
LN
Right Up
RP
Stripe Down
SN
Surface Finish Materials
No.
00
01
02
03
04
Base metal (no additional surface)
Gold 0,25 µm
Gold 0,51 µm (available on request)
Gold 0,76 µm (available on request)
99
Other contact finishes can be produced.
Send specifications for quotation.
Surface (Minimum Thickness 1,27 µm)
No Connector:
Style No.: 39000
Cable Style No.:
Insulation
Material:
Color:
First Conductor:
Conductor
Size:
Stranding:
Material:
39304
39306
39322
PVC
PVC
PVC
Gray
Gray
Multi
Red
Red
Brown
28 AWG
28 AWG
26 AWG
7 x 36
7 x 36
7 x 34
Copper
Copper
Copper
A P Products GmbH
Postfach 1158
D-71089 Weil im Schönbuch
Deutschland
Tel.: +49-7157-5348-0
Fax: +49-7157-5348-39
Web: www.ap-products.de
E-mail: [email protected]
Tinned 2,54 µm (Tin/Lead, non RoHS)
05
Tinned 2,54 µm (RoHS compliant)
