Meritec • 1359 West Jackson Street • Painesville • Ohio • 44077 • USA

(888)637-4832 • (440)354-3148 • (440)354-0509 FAX •

www.meritec.com

4

Facilities

The facilities used for this testing were located at:

APSCO International
3700 Lane Road
Perry, Ohio 44081

APSCO International was chosen for it’s well qualified lead-free SMT and Wave
production lines and knowledgeable personnel. APSCO has been addressing RoHS
compliance since 2003.

Equipment

Equipment used for the Pb free tests was:

Wave Solder Line...Electrovert Econopak Plus
Inspection...Ersa scope
Xray...Nicolet NXR 1510 System

The collection of the time/temperature data was done with a Datapaq Data Logger
and processed using the Datapaq Insight Reflow Tracker v1.40 software.

Additional visual inspection was made using Leica StereoZoom SZ-4
microscopes with 10X eyepieces mounted.

Equipment used for the backwards compatibility (Sn63/Pb37) tests was the same as the
above except:

Wave Solder Line...Electrovert /Vectra Type 400F
