888-24-078-G-04 rev.E • 05/09
5 of 8
Troubleshooting
For problems not addressed above, please Contact Ergotron, Inc., at (800) 888-8458
OR VISIT www.ergotron.com/Dell
Problem Possible Cause Solution
Netbook(s) not charging. Wall power may not be reaching the Mobile
Computing Station Netbooks due to
• unplugged power cord
• improper docking of Netbook(s)
• tripped electrical circuit • Ensure that power cord is plugged-into a wall outlet.
• Verify that Netbook is docked properly: the green tab
at the edge of the dock should be visible.
• Check facility circuit breakers.
• If another electrical device is sharing the same circuit
as the Mobile Computing Station, unplug the other
device.
Power/Fault Status Amber Indicator
light is fl ashing. Indicates possible overheating. • Ensure areas around the fans and vents are
unobstructed.
• Take measures to reduce room temperature below
86° F (30° C).
• Power cord should remain plugged-in so that the
fans continue to operate. Once the temperature has
dropped to a safe level, charging will resume.
Service & Warranty
NOTE: When contacting customer service, please reference the
serial number located above the external cable management bay.
FOR SERVICE ON DELL Mobile Computing Station
CALL (800) 888-8458 OR VISIT www.ergotron.com/Dell
CN-Y88YY-14941-
XXX-1234-A00
S/N 1234
Made in China
DP/N Y88YY
Serial Number is required
for warranty entitlement.
Power System
120 V~, 12 A, 60 Hz
Mobile Computing Station Physical Dimensions
Height 38.7" (982.98 mm)
Length 40" (1016 mm)
Width 24" (609.6 mm)
Weight (without Netbooks) 230 lbs (104 kg)
Weight Capacity
Top Surface 25 lbs (11.34 kg)
Lower Shelf 25 lbs (11.34 kg)
Tip Test/Angle 10°
AC Adapters (25)
Dell Part Number: UU572
Wireless Router
Linksys WRVS4400N Wireless-N Gigabit Security Router with VPN
Specifi cations
Managed Mobile Computing Station only
Ethernet Port Switch -
Cisco SR224G, 24 port, 10/100, 2-Port Gigabit Switch + 2 mini-GBIC
Environmental
Temperature range:
Operating 32° to 86°F (0° to 30°C)
Storage -40° to 149°F (-40° to 65°C)
Relative humidity (maximum):
Operating 10–90% (non condensing)
Storage 5–95% (non condensing)
Altitude (maximum): 6,562 ft (2000 m)
Operational
-40 °C
-40 °F
65 °C
149 °F
Relative
Humidity
Range
5-95% rH
Storage
0 °C
32 °F
30 °C
86 °F
Relative
Humidity
Range
10-90% rH
