Dell™ E-Port II
Quick Setup Guide
1. battery bar adjuster
2. alignment mark
3. battery bar
4. power button
5. eject button
6. security cable slot
7. lock/unlock switch
8. docking connector
1
2
4
5
6
7
8
1. network connector
2. audio connectors (2)
3. USB connectors (3)
4. AC adapter
connector
5. Display Port
6. DVI connector
7. VGA connector
8. USB 2.0/3.0 connectors (2)
9. eSATA connector
10. E-Monitor Stand
connector
1
2
4
5
6
7
8
9
10
3
3
Information in this document is subject to change without notice.
© 2011 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Dell™, and the DELL logo, are trademarks of Dell Inc. Dell disclaims proprietary interest in the marks and names of others.
