Dell Basic PDU - Manual (Page 2)

2 Dell Basic Rack Power Distribution Unit—Product Overview and Specifications
Product Overview and Specifications
The Dell Basic Rack PDU distributes power to the devices in the rack.
O U T L E T S — The Rack PDU has twelve (12) 5-15 R outlets.
P O W E R C O R D — The Rack PDU has a IEC-320 C20 inlet and can be used with a detached power cord (not provided).
H553N
Electrical
Input connection IEC-320 C20 inlet
Acceptable input voltage 100–120 VAC ± 10%
Maximum input current (phase) 15 A (12 A UL(C-UL) derated)
Input frequency 50/60 Hz
Output voltage 100–120 VAC ± 10%
Output connections (12) 5-15 R
Maximum output current (outlet) 5-15 R; 12 A (UL(C-UL) derated)
5-15 R; 15 A (PSE)
Maximum output current (phase) 15 A (12 A UL(C-UL) derated)
Physical
Dimensions
(H x W x D) 52.29 x 5.58 x 4.69 cm
(20.59 x 2.20 x 1.85 in)
Shipping dimensions
(H x W x D) 61.21 x 12.29 x 10.66 cm
(24.10 x 4.84 x 4.20 in)
Weight 1.25 kg (2.75 lb)
Shipping weight 1.6 kg (3.52 lb)
Environmental
Maximum elevation
(above MSL)
Operating
Storage
0 to 3048 m (0 to 10,000 ft)
0 to 15 240 m (0 to 50,000 ft)
Temperature
Operating
Storage
0 to 50°C (32 to 122°F)
–15 to 60°C (5 to 140°F)
Humidity
Operating
Storage
5 to 95%, non-condensing
5 to 95%, non-condensing
Compliance
Safety approvals UL(C-UL), PSE
ROHS Dell 6T198
EU DIRECTIVE 2002/95/EC–latest revision
