2 Dell Metered Rack Power Distribution Unit—Product Overview and Specifications
Product Overview and Specifications
The Dell Metered Rack PDU distributes power to the devices in the rack.
O U T L E T S . The Rack PDU has twenty-one (21) IEC-320-C13 outlets and six (6) IEC-320-C19 outlets.
P O W E R C O R D . The Rack PDU has an IEC-320-C20 inlet and can be used with a detachable power cord (not provided).
K535N
Electrical
Input connection IEC-320-C20
Acceptable input voltage 100–240 VAC +6%, -10%
Maximum input current (phase) 16 A
Input frequency 50/60 Hz
Input power 3.8 kVA UL and C-UL (derated), PSE, International
Output voltage 100–120 VAC (Line-to-Neutral)
Output connections Twenty-one (21) IEC-320-C13; Six (6) IEC-320-C19
Maximum output current (outlet) IEC-320-C13: 12 A; IEC-320-C19: 16 A UL and C-UL
(derated), PSE
IEC-320-C13: 10 A; IEC-320-C19: 16 A International
Maximum output current (phase) 16 A UL and C-UL (derated), PSE, International
Physical
Dimensions
(H x W x D) 162.5 x 5.5 x 4.6 cm
(64.0 x 2.2 x 1.7 in)
Shipping dimensions
(H x W x D) 187.5 x 22.6 x 13.5 cm
(73.8 x 8.9 x 5.3 in)
Weight 3.9 kg (8.5 lb)
Shipping weight 5.7 kg (12.5 lb)
Environmental
Maximum elevation
(above MSL)
Operating
Storage
0 to 3048 m (0 to 10,000 ft)
0 to 15 240 m (0 to 50,000 ft)
Temperature
Operating
Storage
0 to 50°C (32 to 122°F)
–15 to 60°C (5 to 140°F)
Humidity
Operating
Storage
5 to 95%, non-condensing
5 to 95%, non-condensing
