2 Dell Basic Rack Power Distribution Unit—Product Overview and Specifications
Product Overview and Specifications
The Dell Basic Rack PDU distributes power to the devices in the rack.
O U T L E T S — The Rack PDU has eight (8) C13 outlets.
P O W E R C O R D — The Rack PDU has an IEC-320 C14 inlet and can be used with a detached power cord (not provided).
J541N
Electrical
Input connection IEC-320 C14 inlet
Acceptable input voltage 100–240 VAC ± 10% (UL(C-UL))
200–240 VAC ± 10% (International)
Maximum input current (phase) 15 A (12 A UL(C-UL) derated)
10 A (International)
Input frequency 50/60 Hz
Output voltage 100–240 VAC ± 10% (UL(C-UL))
200–240 VAC ± 10% (International)
Output connections (8) C13
Maximum output current (outlet) C13; 12 A (UL(C-UL) derated)
C13; 10 A (International)
Maximum output current (phase) 12 A (UL(C-UL) derated)
10 A (International)
Physical
Dimensions
(H x W x D) 23.97 x 4.36 x 9.29 cm
(9.44 x 1.72 x 3.66 in)
Shipping dimensions
(H x W x D) 28.60 x 21.03 x 13.00 cm
(11.26 x 8.28 x 5.12 in)
Weight 0.90 kg (2.00 lb)
Shipping weight 1.37 kg (3.01 lb)
Environmental
Maximum elevation
(above MSL)
Operating
Storage
0 to 3048 m (0 to 10,000 ft)
0 to 15 240 m (0 to 50,000 ft)
Temperature
Operating
Storage
0 to 50°C (32 to 122°F)
–15 to 60°C (5 to 140°F)
Humidity
Operating
Storage
5 to 95%, non-condensing
5 to 95%, non-condensing
Compliance
Safety approvals UL(C-UL), VDE, IRAM, SABS, GOST-R,
SONCAP, KC, CE
ROHS Dell 6T198
EU DIRECTIVE 2002/95/EC–latest revision
