Dell PowerEdge C6145 - Manual (Page 14)

Getting Started With Your System | 14
Video 15-pin D-Sub VGA
Management port Dedicated Ethernet port for remote
management access
Video (Per System Board)
Video type On-board AST2050 video controller
Video memory 8 MB
Power
AC power supply (per power supply)
Wattage
1023 W low line/1100 W high line
Voltage 100-240 V CA, 50-60 Hz, maximum
input current: 12.0 Amps
Heat dissipation 4217.063 BTU/hr maximum
Wattage 1400 W
Voltage 200-240 V CA, 50-60 Hz, maximum
input current: 8.6 Amps
Heat dissipation 5724 BTU/hr maximum
Maximum inrush current Initial In-rush Current cannot exceed 55
Amps (peak). Secondary In-rush
Current cannot exceed 35 Amps (peak).
Battery (per system board)
System battery CR 2032 3.0-V lithium ion coin cell
RAID battery (optional) 3.7-V lithium ion battery pack
Physical
Height 8.76 cm (3.45 in)
Width 44.8 cm (17.6 in)
Depth 79.0 cm (31.1 in)
Weight (maximum
configuration) 42 kg (92.61 lb)
Weight (empty) 16.5 kg (36.38 lb)
