10

Getting Started With Your System

Connecting the Power Cable(s)

Connect the system’s power cable(s) to the system.

CAUTION:

Both the 120 V (LV) and the 230 V (HV) power modules provide IEC 320

C-13 output receptacles. Only use a power cord rated for the input power source
rating labeled next to the input connector on the power module back panel.

CAUTION:

You must always verify the voltage rating of the BPS. Connecting a 230

Vac into a 120 V BPS will damage the BPS.

Open the spring-loaded interlock cover for the input connector and connect the
power cable to the BPS.
