Dell PowerVault DL2200 CommVault - Manual (Page 11)

Getting Started With Your System
9
Minimum RAM 1 GB with a single processor (1 DIMM per
processor)
Maximum RAM 64 GB (8 GB dual- and quad-rank DIMMs)
Drives
Hard drives Up to twelve 3.5" hot-swappable SAS, SATA,
or SSD drives and up to two cabled 2.5" SAS
or SSD drives
NOTE:
The operating system is installed on the
internal hard drives in a RAID 1 configuration.
Optical drive Optional external USB DVD-ROM
Connectors
Back
NIC Two RJ-45 (for integrated 1-GB NICs)
Serial 9-pin, DTE, 16550-compatible
USB Two 4-pin, USB 2.0-compliant
Video 15-pin VGA
Front
Video 15-pin VGA
USB One 4-pin, USB 2.0-compliant
Internal
USB Two 4-pin, USB 2.0-compliant
Video
Video type Matrox G200, integrated in the BMC
Video memory 8 MB
Memory (continued)
