12 | English
1 609 92A 06C | (7.3.13) Bosch Power Tools
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Tool holder
2 Opening for drift
3 Gear selector
4 Thread for auxiliary handle
5 Auxiliary handle (insulated gripping surface)
6 Lock-on button for On/Off switch
7 On/Off switch
8 Handle (insulated gripping surface)
9 Drift
10 Reducing sleeve*
11 Tapered arbor*
12 Key chuck*
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Noise/Vibration Information
Measured sound values determined according to EN 60745.
Typically the A-weighted noise levels of the product are:
Sound pressure level 86 dB(A); Sound power level 97 dB(A).
Uncertainty K =3 dB.
Wear hearing protection!
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN 60745:
Drilling into metal: a
h
=3.0 m/s 2 , K<1.5 m/s 2 .
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep hands warm, organise work patterns.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 60745
according to the provisions of the directives 2011/65/EU,
2004/108/EC, 2006/42/EC.
Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
D-70745 Leinfelden-Echterdingen
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
11.02.2013
Assembly
 Before any work on the machine itself, pull the mains
plug.
Auxiliary Handle
 Operate your machine only with the auxiliary handle 5.
Screw the auxiliary handle 5 into the thread 4 on the gear
head.
Changing the Tool (see figure A)
Drilling tools with a MK3 morse taper can be inserted directly
into the tool holder 1. For drill bits with MK2 morse taper, use
the reducing sleeve 10.
Pay attention that the morse cone and the morse taper are
free of grease.
Rotary drill GBM 32-4
Article number 0 601 130 2..
Rated power input W 1500
Output power W 1000
No-load speed
– 1st gear
– 2nd gear
– 3rd gear
– 4th gear
min -1
min -1
min -1
min -1
210
330
470
740
Rotational speed under load
– 1st gear
– 2nd gear
– 3rd gear
– 4th gear
min -1
min -1
min -1
min -1
120
185
265
420
Rated torque (1./2./3./4. gear) Nm 80/52/36/23
Max. drilling dia.
– Steel
– Wood
– Aluminium
mm
mm
mm 32
70
50
Tool holder MK 3 – DIN 228
Weight according to
EPTA-Procedure 01/2003
kg 7.3
Protection class / II
The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.
Starting cycles generate brief voltage drops. Interference with other
equipment/machines may occur in case of unfavourable mains system
conditions. Malfunctions are not to be expected for system impedances
below 0.36 ohm.
Dr. Egbert Schneider
Senior Vice President
Engineering Helmut Heinzelmann
Head of Product Certification
PT/ETM9
