14 | English
1 609 92A 01E | (21.11.12) Bosch Power Tools
Product Description and
Specifications
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
While reading the operating instructions, unfold the graphics
page for the machine and leave it open.
Intended Use
The machine is intended for sawing wood, plastic, metal and
building materials while resting firmly on the workpiece. It is
suitable for straight and curved cuts. When using the appro-
priate bimetal saw blades, it is possible to cut flush to the
workpiece surface. The saw blade recommendations must be
observed.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Saw blade*
2 Adjustable footplate
3 Saw blade holder
4 Locking sleeve for saw blade
5 Stroke rod
6 Stroke speed selector switch
7 On/Off switch
8 Battery unlocking button
9 Battery pack*
10 Handle (insulated gripping surface)
11 Button for charge-control indicator*
12 Battery charge-control indicator*
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Noise/Vibration Information
Measured sound values determined according to EN 60745.
Typically the A-weighted sound pressure level of the product
is 77 dB(A). Uncertainty K=3 dB.
The noise level when working can exceed 80 dB(A).
Wear hearing protection!
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN 60745:
Cutting board: a
h
=24 m/s 2 , K=1.5 m/s 2 ,
Cutting wooden beam: a
h
=24.5 m/s 2 , K=1.5 m/s 2 .
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep hands warm, organise work patterns.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 60745
according to the provisions of the directives 2011/65/EU,
2004/108/EC, 2006/42/EC.
Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
D-70745 Leinfelden-Echterdingen
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Leinfelden, 25.10.2012
Assembly
Battery Charging
 Use only the battery chargers listed on the accessories
page. Only these battery chargers are matched to the lith-
ium ion battery of your power tool.
Note: The battery is supplied partially charged. To ensure full
capacity of the battery, completely charge the battery in the
battery charger before using your power tool for the first time.
Sabre saw GSA 18 V-LI
Article number 3 601 F4J 0..
Rated voltage V= 18
Stroke rate at no load n
0
– 1st gear
– 2nd gear min -1
min -1
0 –2400
0 –2700
Tool holder SDS
Stroke rate control 
Stroke mm 28
Cutting depth, max.
– in wood
– in non-alloy steel
– Pipe diameter
mm
mm
mm 250
20
130
Weight according to
EPTA-Procedure 01/2003
kg 3.2/3.4*
* dependent of the battery pack being used
Dr. Egbert Schneider
Senior Vice President
Engineering Helmut Heinzelmann
Head of Product Certification
PT/ETM9
