Garmin nuvi 465TF - Manual (Page 3)

nüvi465quickstartmanual 3
Set Up Your nüvi
Attach the Adhesive Disk and
the Mounting Base to Your
Dashboard
caution: The permanent adhesive
disk is extremely difficult to remove.
1. Clean and dry the area where you
want to place the mounting base.
2. Select the adhesive disk you want
to use, and remove one side of the
backing.
Permanent Disk
3. Place the adhesive disk on the bottom
of the mounting base, and remove the
other side of the backing.
4. Place the mounting base so that the
locking lever is facing you. Position
the base on the cleaned area. Apply
pressure to adhere the base to the
dashboard.
5. Snap the cradle onto the mounting
arm.
Cradle
Mountingarm
6. Slide the mounting arm with cradle
attached into the mounting base.
Mountingarm
withcradle
Mounting
base
7. Slide the locking lever into the locked
position.
Before mounting the traffic receiver, see the
Important Safety and Product Information guide
for information about laws pertaining to windshield
mounting.
