I/o panel, Z 8 7 pro3, English – ASRock Z87 Pro3 User Manual
Page 5
Z87 Pro3
3
English
I/O Panel
No. Description
No. Description
1
USB 2.0 Ports (USB01)
8
Microphone (Pink)
2
D-Sub Port
9
Central / Bass (Orange)
3
LAN RJ-45 Port*
10
USB 3.0 Ports (USB3_23)
4
Side Speaker (Gray)
11
USB 3.0 Ports (USB3_01)
5
Rear Speaker (Black)
12
DVI-D Port
6
Line In (Light Blue)
13
HDMI Port
7
Front Speaker (Lime)**
14
PS/2 Keyboard Port
8
9
14
10
11
12
13
1
2
3
5
4
7
6
