Chapter 2: Jumpers and Connectors
Jumpers and DIP Switch Settings
CMOS Clear Select
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP1
1 3
AT/ATX Selection
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP8
1 3
Pin
1-2 On
2-3 On
1-2 On: default
Pin
1
2
3
Settings
Normal
Clear BIOS
Pin
1-2 On
2-3 On
2-3 On: default
Pin
1
2
3
Settings
AT Mode
ATX Mode
Definition
NC
RTC Power
GND
Definition
AUTO (AT MODE)
PWRBT In
Manual ( ATX MODE)
