AcuConnect-LTE User Quick Guide
AcuConnect-LTE
User Quick Guide
4G Wireless Mobile
Broadband Router
Acura Embedded Systems Inc.
Overview
AcuConnect-LTE features WAN port for high-speed connectivity, so you can choose
any 4G SIM card to plug in SIM card slot.
Rear View
Front View
AcuConnect-LTE
supports the following features.
• Input voltage: DC 6V to 30V
• Power:DC12V,3A Power Adapter
• Interface:2 LAN 10/100Mbps UTP Ports
• Flash:4 MB NOR Flash
• RAM:32 MB SDRAM
•
Button: WPS/Reset
• Antenna:5dBi Antenna X 2
• Tx Power:20dbm 802.11g
• EVM:3% 802.11g
• LED Indicators:Power,WAN,LAN,WLAN,3G,WPS
• Dimension:115x100x35 mm Weight: 150g
• Humidity:10-90% (Non-Condensing)
• Temperature: -30C to +60C
• WLAN Operation Band: Complies with 2.4GHz ; 802.11b/g/n standards
3 G Antenna WiFi Antenna
