Acura Embedded AcuConnect-LTE User Manual
Acuconnect-lte, Lte-mobile router, Ram:32 mb sdram

LTE-Mobile Router
Front Side
LAN
LED indicator Power, WAN, LAN, WLAN, 4G,WPS
Button
Antenna
SIM Card Socket
2 x LAN 10/100Mbps UTP Ports
WPS/Reset
5dBi Antenna X 2
1 x SIM Card Socket with eject
Power Input
Power Adaptor
6V - 30V DC Power Input
12V DC / 3A
Mechanical
Construction
Mounting
Weight
Dimensions
Aluminum alloy
Supports vehicle-mount
150 g (bare-bone)
115 x 100 x 35 mm
Support Information
AcuConnect-LTE
LTE (4G) wireless mobile with
2
LAN Ports Broadband WIFI Router
Flash:4 MB NOR Flash
Wireless support LTE (4G)/ SIM Card
6V - 30V DC Power Input
WLAN: Complies with 2.4GHz ; 802.11b/g/n
Support 2 x 5dBi Antenna
Support 2 x LAN 10/100Mbps UTP Ports
Features
Environmental
Operating Temp.
WLAN Operation Band
Relative Humidity
-30ºC ~ 60ºC
Complies with 2.4GHz ;
802.11b/g/n standards
10-90% (Non-Condensing)
0% RH– 95% RH
ACURA EMBEDDED SYSTEMS INC.
Unit #1-7711 128 Street Surrey.BC
V3W 4E6 Canada
Ph:(604)502-9666 Fax:(604)502-9666
www.acuraembedded.com
Toll-Free: 1-866-502-9666
RAM:32 MB SDRAM
Back Side
Power Input
12V DC
Power Requirement
