Chapter 3: System Setup
2. Remove the mounting screws of the drive bay.
3. Remove the drive bay. The drive bay is used to hold a SATA hard drive.
Mounting
screw
SATA power cable
and SATA cable
35
4. Place the SATA hard drive on the drive bay.
SATA drive
Drive bay
5. Align the mounting holes that are on the sides of the SATA drive
with the mounting holes on the drive bay and then use the provided
mounting screws to secure the drive in place.
Mounting
screw
