Specifications
All informations are subject to change without notice
www.acuraembedded.com
System
In Front Control
I/O Ports
Mechanical &
Environment
Power Management
option by
snap-on module
CPU
Memory
Storage
Display
Display Resolution
Display Brightness
Audio
Communication
RFID
Webcam
TPM
WWAN
GPS
USB Port
Serial
Ethernet
Audio Jack
Docking Connector
DC Jack
Micro SD Slot
Dimensions/Weight
Certifications
Operating System
Protection Class
Drop
Shock
Temperature
Humidity
Battery
Power Adapter
Intel® Atom™ N2600 1.6GHz Dual Core Processor (Cedar Trail)
2GB DDRIII 800 SO-DIMM
32GB SATA half-slim size SSD
7-inch LED backlight screen with 5-wire Resistive Touch
1280 (W) x 800 (H) WSXGA
400nits / optional 500nits Sunlight Readable
1 x High quality speaker
Wi-Fi IEEE 802.11 a/b/g/n and Bluetooth 4.0
ISO/IEC 14443A, 14443B
Mifare 1K/4K, Ultralight
NFC-IP1 Protocol
2 Mega-pixel camera audio input (Front bezel)
5 Mega-pixel camera with LED light (Rear bezel)
TPM 1.2 (option)
3.5G or LTE (option)
Embedded
1 x Power button, 6 x Program function button, 1 x Finger print
2 x USB 2.0 type A
1 x RS-232
1 x 10/100/1000 Mbps (RJ45)
1 (for microphone and headphone)
1
1
1
225(W) x 168(H) x 26.5(D) mm , 0.85kg (1.87lb)
CE, FCC
WES7-WS7P, Win7 Pro. (Embedded)
IP65
5-ft drop resistance (MIL-STD-810G)
Operating : 40g, 11ms, MIL-STD-810G 516.6
Operating : -20°C to +50°C Storage : -30°C to +70°C
5~95% without condensation
Internal Smart Lithium Polymer battery, 3000mAH, 7.4V
AC 100V~240V, 50~60Hz input; 19V
DC
@3.42A, 65W
Power Key
5 Mega-pixel Camera
USB
Audio Jack
Micro SD
DC-In
Function Key
Finger Print
Docking Connector
Function Key
2 Mega-pixel
Camera
USB
RS232
RJ45
MSR/Barcode Scanner
I/O Diagram
Accessories
E
xternal Battery
M
SR/Barcode Scanner
S
tylus
coming...
