Specification
Speed
Dome
Video
Server
Video compression H.264 and Motion JPEG, dual codec
Resolution
960H: 960 x 480 (NTSC) / 960 x 576 (PAL) , D1: 720 x 480 , CIF: 352 x 240
Frame rate
H.264 : up to 30 (NTSC) / 25 (PAL) FPS at 960H resolution
Motion JPEG : up to 30 (NTSC) / 25 (PAL) FPS at D1 resolution
Streaming 4-Streaming
Video streaming RTP/HTTP, RTP/TCP, RTP/UDP, Multicast Streaming
Video bitrate
128Kbps to 3Mbps
Change frame rate and bitrate on-the-fly
CBR/VBR/GOP supported
Security
Base64 HTTP encryption
Multiple user access levels with password protection
10 user accounts available
Users 8 simultaneous users
OSD Overlay for date and time
Alarm/motion
Audio detection
Motion detection
External digital input alarm
Image upload over FTP and e-mail by above alarm signals
CPU, memory Embedded SoC CPU at 528Mhz, 256 MB DDR, 256 MB flash memory
IR cut removable Auto, day , night, scheduling, day & night models only Yes
Alarm input TTL input +3VDC to +5VDC, alarm input models only 3 In 1 In
Alarm output DC 24 1A, dry-contact (N.O./N.C.), alarm output models only 1 Out 2 Out
Maintenance Firmware update via HTTP, Firmware available at web site
Network interface 10Mbps/100Mbps, RJ-45
Two-way audio G.711 u-Law, audio model only
PC requirement
OS: Windows 2000, Windows XP, Windows Vista, Windows 7
Browser: Windows Internet Explorer 6.0 or above
CPU: Intel Pentium 4 1.8GHz or above
RAM: 1GB or above
Network protocols
IP, TCP, UDP, HTTP, SMTP, NTP, DDNS, UPnP, FTP, ARP, DHCP, PPPoE,
DNS, RTSP, RTCP, Telnet, ONVIF
Mobile phone &
PDA
Support iPhone, iPad, and Android
System integration ONVIF and HTTPAPI
AIM2 CMS
AIM HD 2.6 support
OS Embedded Linux 2.6.32
Design and specification are subject to change without further notice.
