Actron Scan Tools PIDs Supplement - Manual (Page 15)

• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 13
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
CYL 6 MISFIRE Cylinder Misfire
CYL 7 MISFIRE Cylinder Misfire
CYL 8 MISFIRE Cylinder Misfire
CYL ID Cylinder Identification
CYL KNKRET Cylinder Knock Retard
CYL MDE MIS Cylinder Mode Misfire Index
CYL MISFIRE Cylinder Misfire
CYLINDER AIR Cylinder Air
CYLS PASSED/FAILED Cylinders Failed Or Passed
DBL STRT OVRD Double Start Override
DCL FL MDE Decal Fuel Mode
DECAL EWMA Decal EWMA
DECEL FL MDE Decel Fuel Mode
DEFROST SW Defrost Switch
DES CYL AIR Desired Cylinder Air
DES EGR POS Desired Linear EGR Position
DES G FLOW Desired Gas Mass Flow
DES IAC Desired Intake Air Control
DES IDLE Desired Idle Speed
DES INJ TIM Desired Diesel Injection Pump Timing
DES L PRS Desired Lime Pressure
DES TORQUE Desired Torque Level
DIESLE EGR SYSTEM Diesle Exhaust Gas Recirculation System
DIS CYL EVENT Distributorless Ignition System Cycle Event
DIS CYC EVENT Distributorless Ignition System Cycle Event
DIS SEN STAT Distributorless Ignition System Sensor Status
DIS SIG STAT Distributorless Ignition System Signal Status
DLV ENG TR Delivered Engine Torque
DLV TR DR H Delivered Torque Driver High
DLV TR DR L Delivered Torque Driver Low
DPF EGR Delta Pressure Feedback EGR Pressure Sensor
DRIVER Driver 1
DS DESIRED Down Shift Desired
DS IN PROG Down Shift In Progress
DS REQ Down Shift Requested
DSL EGR SYS Diesle Exhaust Gas Recirculation System
DTC CNT Total Number of Fault Codes And Pending Codes
DTC THIS IGN DTC Set This Ignition
ECBM VOLTS Electronic Control Braking Module Voltage
ECL LOW LAMP Low Engine Coolant Level Lamp
ECT Ect Engine Coolant Temperature
ECT A/D Engine Coolant Temperature Sensor Analog To Digital Reading
ECT AT MISF Engine Coolant Temperature at Misfire
ECT GAUGE Engine Coolant Temperature Gauge
ECT SENSOR(V) Engine Coolant Temperature Sensor Voltage
ECT STARTUP Engine Coolant Temperature at Start Up
ECT STRTUP Engine Coolant Temperature at Start Up
ECT TCM Engine Coolant Temperature TCM
ECT TEMP (°F)/(° C) Engine Coolant Temperature
ECU RST INIT Electronic Control Unit Reset - Initialized
ECU RST-2X LOSS Electronic Control Unit Reset - 2X Buss Loss
ECU RST-BATT L Electronic Control Unit Battery Loss
ECU RST-CLK L Electronic Control Unit Reset - Clock Loss
ECU RST-EXT External Electronic Control Unit Reset
PID Extended Description
