7 Philips HeartStart OnSite Defibrillator
Philips HeartStart OnSite Defibrillator
Product specifications
Defibrillator
Defibrillator Model HeartStart M5066A
Defibrillator Family HS1
How Supplied Defibrillator, Owner’s Manual, battery, 1 adult
SMART Pads cartridge, Quick Reference Guide and
Quick Start poster
Waveform Truncated Exponential Biphasic.Waveform parameters
adjusted as a function of each patient’s impedance.
Energy Single energy output. Adult: nominal 150 Joules into a
50 ohm load. Infant/Child: nominal 50 Joules into a 50
ohm load. Automatically set based on type of SMART
Pads cartridge installed.
Shock-to-Shock Typically less than 20 seconds between shocks in a series.
Cycle Time
Quick Shock Able to deliver a shock after the end of a CPR interval,
typically in eight seconds.
Voice Instructions Detailed voice messages guide responder through use
of the defibrillator.
CPR Coaching Instructions for adult and infant/child CPR available at
user’s option.
Shock Delivery Via adhesive pads placed on patient’s bare skin as
illustrated on pads.
Controls Green SMART Pads cartridge handle, green On/Off
button, blue i-button, orange Shock button
Indicators Ready light; blue i-button; caution light
Physical Specifications
Size 2.8 x 7.4 x 8.3 inches (7 x 19 x 21 cm) H x D x W
Weight With battery and pads case: 3.3 lbs. (1.5 kg)
Without battery or pads case: 2.4 lbs. (1 kg)
Environmental/Physical Requirements
Sealing Solid objects per EN60529 class IP2X
Drip-proof per EN60529 class IPX1
Temperature Operating: 32º - 122º F (0º- 50º C)
Standby: 50º - 109º F (10º- 43º C)
Humidity Operating: 0% to 95% relative, non-condensing
Standby: 0% to 75% relative, non-condensing
Altitude Operating: 0 to 15,000 feet
Standby: 0 to 8,500 feet > 48 hours and 8,500 to
15,000 feet < 48 hours
Shock/Drop Abuse Withstands 1 meter drop to any edge,corner or surface.
Vibration Meets EN1789 random and swept sine, road ambulance
specification in operating and standby states.
EMI (Radiated/Immunity) Meets EN55011 Group 1 Level B Class B and
EN61000-4-3.
Patient Analysis System
Patient Analysis Evaluates patient ECG to determine if a rhythm is
shockable. Rhythms considered shockable are
ventricular fibrillation (VF) and certain ventricular
tachycardias (VT) associated with lack of circulation.
For safety reasons, some VT rhythms associated with
circulation will not be interpreted as shockable, and
some very low-amplitude or low-frequency rhythms
will not be interpreted as shockable VF.
Sensitivity/Specificity Meets AAMI DF80 guidelines and AHA
recommendations for adult defibrillation (Circulation
1997;95:1677-1682).
Artifact Detection The effects of pacemaker artifact and electrical noise
are minimized with artifact detection.
Battery (M5070A)
Type 9 Volt DC, 4.2 Ah, composed of disposable long-life
lithium manganese dioxide primary cells.
Capacity Minimum 200 shocks or 4 hours of operating time
(EN 60601-2-4:2003)
Install-by Date Battery is labeled with an install-by date of at least five
years from date of manufacture.
Standby Life Four years typical when battery is installed by the
install-by date. (Will power the AED in standby state
within the specified standby temperature range,
assuming one battery insertion test and no
defibrillation uses.)
SMART Pads
Adult SMART M5071A defibrillation pads for patients 8 years of age
Pads Cartridge and older or 55 lbs. (25 kg) and over.
Infant/Child SMART M5072A defibrillation pads for patients under 8 years
Pads Cartridge of age or 55 lbs. (25 kg). Rx only.
Energy Delivered Adult: nominal 150 Joules into a 50 ohm load
Infant/Child: nominal 50 Joules into a 50 ohm load
How Supplied Disposable cartridge, containing adhesive
defibrillation pads, clicks into defibrillator for an
integrated pads solution.
Active Surface Area 13.2 in 2 (85 cm 2 ) each
Cable Length Adult pads: 54 in (137.1 cm)
Infant/Child pads: 40 in (101.6 cm)
Use-by Date Cartridge is labeled with a use-by date of at least two
years from date of manufacture.
Training Pads
Adult Training Pads M5073A
Cartridge
Infant/Child Training M5074A
Pads Cartridge
Function Special pads put HeartStart OnSite into training mode
and disable its energy delivery capability.Training pads
feature 8 real-world training scripts. Used with training
mat (included) or with adapters on manikins.
Automated and User-activated Self-tests
Daily Automatic Self-tests Tests internal circuitry, waveform delivery system, pads
cartridge and battery capacity.
Pads Integrity Test Specifically tests readiness-for-use of pads
(gel moisture).
Battery Insertion Test Upon battery insertion, extensive automatic self-tests
and user-interactive test check device readiness.
Status Indicator Blinking green “Ready” light indicates ready for use.
Audible “chirp” indicates need for maintenance.
Data Recording and Transmission
Infrared Wireless transmission of event data to a PC or Palm ®
PDA, using the IrDA protocol.
Data Stored First 15 minutes of ECG and the entire incident’s events
and analysis decisions.
* Refer to the HeartStart OnSite Defibrillator Owner’s Manual for detailed product instructions.
All specifications based on 25º C unless otherwise noted.The defibrillator and its accessories are made
of latex-free materials.
