11 EN
1.6 CE marking
The product complies with EU Directive 93/42/EEC for
medical equipment.
2.1 Warnings and symbols
The following warnings and symbols are used in these
operating instructions:
2.2 General instructions
3.1 Scope of delivery
The AQUATEC OCEAN VIP is supplied with the fol-
lowing parts (fig. 2):
1 Head support
2 Backrest with cover and armrests
3 Operating instructions (in plastic bag)
4 Screws (4 x) for backrest
5 Cable ties (2 x)
6 Allen key
7 Clips (2 x) for footrests (in plastic bag)
8 Footrests with heel loops (2 x)
9 Seat frame with seat plate and side sections with
casters
10 Clips (2 x) for height adjustment (inserted from the
inside)
3.2 Technical data
Dimensions
Width
576 mm
Depth 1,058 mm
Height (without head support) 1,098
−
1,198 mm
Seat width 500 mm
Seat depth 452 mm
Seat height 500/550/600 mm
Min. distance between floor
and holder for the sanitary pan
422
−
522 mm
Weight approx. 21 kg
Load capacity 150 kg
The label (fig. 1) provides important technical informa-
tion.
The label is attached to the inside of the right side sec-
tion.
You can easily disassemble the commode into its com-
ponent parts (section 3.1) for transport.
For detailed instructions on how to dismantle the de-
vice, please refer to section 5.
*
CAUTION!
This notice indicates a potential hazard.
Not following these instructions can re-
sult in injury or damage.
Important!
This symbol indicates additional instructions,
information or tips.
Lock the brakes in the parked position.
Only use the commode indoors and on even,
flat surfaces.
If you detect any malfunction, please contact
your authorised dealer immediately.
Do not modify or reconstruct the device.
Never carry out work on the pneumatic
springs. Please contact your authorised
dealer immediately if a pneumatic spring is
damaged or faulty.
Observe the information on the label. Do not
overload the commode.
2 Safety instructions
* In the text, a picture illustrating the type of risk re-
places the asterisk.
Important!
● Before setting up, inspect all parts for dam-
age during transport.
● This section describes the assembly. Disas-
sembly is carried out in reverse order.
● During assembly, make sure the parts are
positioned correctly in relation to each other
(fig. 2).
3 Description
4 Transport
5 Setting up
