Activeforever Health Craft Assista Rail (Standard) - Manual (Page 2)

Secure Safety Strapping (MANDATORY)
For Single to Queen Sized Beds For King or Larger Sized Beds
C
Place mattress back on top of the box spring. Place the
strap around each rail, loop around the metal bed frame
and tighten. If the Assista-Cane
TM is to be installed, refer
to installation instructions on Page 1.
Place mattress back on top of the box spring. Attach the straps
from the two rails together to make one large strap. Place strap
around the rail, under the bed, around the other rail and tighten.
If the Assista-Cane
TM is to be installed, refer to installation
instructions on Page 1.
(REFER TO FRONT FOR GENERAL INSTALLATION & SAFETY GUIDELINES)
INSTALLATION OF BED RAIL ON BOTH SIDES OF BED Pg.2
Model AST-C,AST-S,
AST-C-AK & AST-KIT
Installation Preparation
B C
Secure Safety Clamps (MANDATORY)
A
Remove Cross Beam
Spread rail legs apart with rubber hammer (A1)
to remove cross bar (A2).
Make sure cross bars
are removed in step
A1 / A2. Remove bed
mattress, pillows, etc.
to expose box spring.
Locate tube furthest
from head of bed,
adjacent to hip as
shown.
Tighten the bolts on the safety clamp to secure the two rails
together (x2).
Adjust the distance of the
rails so it fits around the
mattress (B1).
A1
A2
B1
