PresSsion ® Gradient Sequential - Multi 3 & Multi 6
N NO OM ME EN NC CL LA AT TU UR RE E
1
3 4 5
1 . Blanking Plug - Remove this plug in order to inflate or deflate a second garment.
Keep this plug inserted when inflating or deflating only one garment.
2.
Air Supply Connections - Point of attachment for air hoses.
3.
Power Supply Cord Receptacle - Location of Power Input from Power Supply
Cord.
4.
Power Switch - ON/OFF toggle switch.
5.
Pressure Regulator Dial - Sets pressure.
6.
Deflation Time Control Dial - Sets the time during which the garment is deflated,
plus the rest of the interval before the next cycle.
7.
Inflation Time Control Dial - Sets the time during which the garments chambers
will be sequentially pressurized. Includes inflation time and time held at selected
pressure.
8. Therapy Timer Control Dial - Sets the time for the actual compression treatment
time.
9.
Start Button - Begins compression treatment.
10.
LCD Pressure Display - Displays the pressure in the garment at all times.
2 1 4
5
1.
Pressure Regulator Dial - Sets pressure.
2. Air Supply Connections - Point of attachment for air
hoses.
3.
Power Supply Cord Receptacle - Location of Power
Input from Power Supply Cord.
4
. Blanking Plug - Remove this plug in order to inflate or
deflate a second garment. Keep this plug inserted
when inflating or deflating only one garment.
5.
Power Switch - ON/OFF toggle switch.
6. LCD Pressure Display - Displays the pressure in the
garment at all times.
