ACR30 Reference Manual
Version 3.3 January 2009 Page 23 of 44
ACR30
Option Bit 0 (LSB bit): Select for PPS mode
Specifies reader Ù card communication speed
0 : baud rate to/from the card is from 9600 bps to 96000 bps (default)
1 : baud rate to/from the card is at 9600 bps only
Bit 4 : Select for EMV mode
Specifies whether the reader is in EMV mode
0 : reader not in EMV mode (default)
1 : reader in EMV mode
Bit 2, 3, 5, 6 and 7
Reserved
Response data format
No response data
9.2. Card Commands
The available commands and the parameters specified in the card commands as well as the data
transmitted in the response from the ACR30 depend on the selected card type.
'104' - type non-reloadable Token Counter Cards (*)
9.2.1.1. RESET (*)
This command powers up the card inserted in the card reader and performs a card reset.
If the card is powered up when the command is being issued, only a reset of the card is carried out;
the power supply to the card is not switched off.
Command format
Instruction
Code
Data length
80
H
00
H
Response data format
ATR
ATR Four bytes Answer-To-Reset read from the card.
The ATR bytes are read from the card with LSB first, i.e., the first bit read from the card
is the LSB of the first ATR byte.
