Figure 15: ground wire – ACR&Artex ME406 ACE 455-0023 User Manual
Page 25
Artex Products / ACR Electronics, Inc.
570-0023 Rev. G
Page 25 of 33
10.3.8 Position the ground wire (black) along the side of the plastic cell holder and away from
the screw boss.
Figure 15: Ground Wire
10.3.9 Refer to Subsection 10.5 to install the mating cover.
Black Wire
Screw boss
