FES6841
Fanless Embedded Controller comes with
Intel Atom N270 Processor
FES6841
Fanless Embedded Controller comes with
Intel Atom N270 Processor
4.1 Installation
Insert the FES-6841 CD-ROM into the CD-ROM Drive. The Autorun program will run automati-
cally. You also can choose the drivers to install from step 1 to step 4 in order as following instruc-
tions.
Step 1 - Install INF Driver
1. Click on the Step 1 - Intel INF folder and then double click on the Setup.exe.
2. Follow the instructions that the window shows you
3. The system will help you install the driver automatically
Step 2 - Install VGA Driver
1. Click on the Step 2 - VGA folder and select the OS your system is
2. Double click on the setup.exe file located in each OS folder
3. Follow the instructions that the window shows you
4. The system will help you install the driver automatically
Step 3 - Install Intel LAN Driver
1. Click on the Step 3 - Intel LAN Driver folder and install the LAN1 and LAN2 drivers
accordingly
2. When you install the LAN1 driver, select the LAN1 folder and double click on the Setup.exe;
When you install the LAN2 driver, click on the LAN2 folder and select the OS your system is,
and then double click on the .exe file located in each OS folder
3. Follow the instructions that the window shows you
4. The system will help you install the driver automatically
