RM 6821
21.5” 1920x1080 650-nit High Brightness LCD
8U Rackmount Display Panel
< Part 1 >
< 1.1 > Packag e Content
RM 6821 u n it X 1
- 6ft VG A c able X 1
- Pow er ad apt er X 1
- Pow er c ord X 1
- Fa stener screw for rear bracke t x 2
< 1.2 > Stru cture Diag ram
F ro n t view
1
P ow er ad apter
3
2
R ear view
4
1 L CD panel
2 LC D mem brane
3 Latc h to release the display panel from the
rear brac ket
4 R ear mounting bracket
5 P ower ad apter bask et
5
Po w er c ord
DVI-D
Audio
Power BNC S-Video VG A H DM I
S tandar d
AV3. 0 upgr ade
O ption
out - in - in
Video PC
: DVI-D + VGA + HDMI w / speaker
: DVI-D + VGA + HDMI + BNC + S-Video + audio
: SDI, USB for touchscreen & DC power
