RM 6821
21.5” 1920x1080 650-nit High Brightness LCD
8U Rackmount Display Panel
< 2.3.2 > Picture By Picture ( PBP )
Mode
Display the Sub screen next to the Main screen.
OSD Menu
? MISC ? PIP Mode ? PBP
Main screen Sub screen
Size
LCD Monitor Main / Sub screen
1920 x 1200 955 x 716
1920 x 1080 955 x 716
1440 x 900 715 x 536
1366 x 768 678 x 508
1280 x 1024 635 x 476
< 2.3.3 > PIP / PBP Source
To select an input signal for PIP / PBP Sub screen.
OSD Menu
? MISC ? PIP Source ? VGA / S-Video / Composite / DVI / HDMI / SDI / YPbPr / TV
The PIP / PBP is operable in the following table :
Sub
Main
VGA S-Video Composite DVI-D HDMI SDI YPbPr TV
VGA x o o o o o o o
S-Video o x x o o o o x
Composite o x x o o o o x
DVI o o o x x o o o
HDMI o o o x x o o o
SDI o o o o o x x o
YPbPr o o o o o x x o
TV o x x o o o o x
