APW 5170

17” Industrial Panel Mount Widescreen LCD

< 1.3 > Panel Mount Installation – APW 5170

1

Mounting

bracket

x 4 pcs

2

M4*6mm screw

x 8 pcs

3

M4*50mm screw

x 8 pcs

Hardware set part no. UV-BK#2

Steps

¦

Install 4 mounting brackets with 8 x M4*6mm screws

¦

Adjust the LCD panel with 8 x M4*50mm screws and fix it on the surface.
