Acnodes APW 5170 - Manual (Page 10)

< Part 2 >
< 2.1 > Product Specifications
Mechanical
Design
APW 5170
Front Panel Black, RAL 9005
Rear Casing Dark grey, RAL 7037
VESA Mounting 100 x 100mm
Other Mounting Panel mount
Protection 3mm protective glass
LCD
Panel
Panel Size ( diagonal ) 17.1-inch Widescreen TFT color LCD
Display pixel ( dots x lines ) 1920 x 1200
Brightness ( typ. ) 210
Contrast Ratio ( typ. ) 600:1
Color 16.7M, 8-bit
Viewing Angle ( L/R/U/D ) 65/65/55/55
Response Time ( ms ) 30
Dot pitch ( mm ) 0.191
Display Area ( mm ) 367.20H x 229.50V
Surface treatment Anti-glare, Hard-coating
Surface hardness 3H
Backlight Type LED
MTBF ( hrs ) 20,000
Video
Connectivity
Digital HDMI HDMI 1.1, CEA-861-D
DVI DVI-D, TMDS single link
Analog VGA Analog 0.7Vp-p
Composite ( RCA ) NTSC & PAL
S-Video ( 4-pin ) NTSC & PAL
Plug & Play DVI / VGA VESA EDID structure 1.3
Synchronization VGA Separate, Composite & SOG
Audio
Connectivity
Audio Input Connector 3.5mm stereo jack
Impedance / Power level 30kΩ / 750mV
Audio Output Connector 3.5mm stereo jack
Resistance / Power level 30kΩ / 2.8V
Speaker Output Power 2 x 2W
*When the audio output is connected, speaker output is OFF
Power Power Supply
Range
Auto-sensing 100 to 240VAC,
50 / 60Hz
Power Consumption Screen display ON 34W or less
Power saving mode 4W or less
Power button OFF 1W or less
