Number of organizer
trays in kit.
A closure:0-2
B closure:0-4
D closure:0-8 Ground feed thru lug(s)
G = Grounding
N = None
Raychem Customer
Specification Nnumber
Closure size: A, B or D
Number of round ports
Type of tray
S: only mentioned if it
is the tray, with Stacked
splices (EUR design).
There is no indication
if the splice modules are used
(US design). Splice capacity of
each organiser tray:
A Tray: 08 or 16
B Tray: 12, 16 or 24
D Tray: 36, 48 or 72
No trays = NT Cable Blocking
Components
B = Blocking
N = None Valve for flash
Test
V = Valve
N = None
Ex. FOSC-400D5-36-1-NNN-A6007
D5 D size with 5 circular ports
36 Tray for upto 36 splices using splice modules
1 Closure is delivered with 1 tray
NNV The closure is not equipped with cable blocking, but has a valve for flash testing and no
components for electrical grounding of cable
A6007 Customer control number
2 Product description
2.1 Product designation
Raychem Total closure Outer dia Max.fusion Cable diameter in
description length closure splice capacity Circular port Oval port
min. Max. (250μ fibers) min. max. min. max.
(body) (body + (*) (*) (**) (**)
clamp)
FOSC-400A4 420 152 205 32 5 19 10 25
FOSC-400B2 540 152 205 96 5 32 10 25
FOSC-400B4 540 152 205 96 5 19 10 25
FOSC-400D5 710 240 285 576 5 32 10 25
FOSC sizing information (dimensions in mm)
(*) Cable diameter for 1 cable/port
(**) Cable diameter for 2 cables/port
FOSC-400X X - X X X - X - X X X - X X Y Y
