6
English
Closed front view
+ < > Volume up Increases the sound volume.
+ < > Volume down Decreases the sound volume.
+ Play/Pause Play or pause a selected media file.
+ Stop Stop playing the selected media file.
+ Previous Return to the previous media file.
+ Next Jump to the next media file.
# Icon Item Description
1 Power indicator Indicates the computer's power status.
Battery indicator
Indicates the computer's battery status.
1. Charging: The light shows amber
when the battery is charging.
2. Fully charged: The light shows blue
when in AC mode.
HDD indicator Indicates when the hard disk drive is
active.
Communication
indicator Indicates the computer’s wireless
connectivity device status.
2 Multi-in-1 card reader Accepts Secure Digital (SD),
MultiMediaCard (MMC), Memory Stick
PRO (MS PRO), xD-Picture Card (xD).
Note: Push to remove/install the card.
Only one card can operate at any time.
Hotkey Icon Function Description
1 2 3
