9
Eng
lis
h
Base view
7 DC-in jack Connects to an AC adapter.
# Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Hard disk bay Houses the computer's hard disk (secured
with screws).
Memory compartment Houses the computer's main memory.
3 Battery release latch Releases the battery for removal.
4 Battery lock Locks the battery in position.
Environment • Temperature:
• Operating: 5 °C to 35 °C
• Non-operating: -20 °C to 65 °C
• Humidity (non-condensing):
• Operating: 20% to 80%
• Non-operating: 20% to 80%
# Icon Item Description
1
2
4
3
