7
Eng
lis
h
Closed front view
Left view
# Icon Item Description
1 Multi-in-1 card
reader Accepts Secure Digital (SD),
MultiMediaCard (MMC), Memory Stick
(MS), Memory Stick PRO (MS PRO),
xD-Picture Card (xD).
Note: Push to remove/install the card. Only
one card can operate at any given time.
# Icon Item Description
1 DC-in jack Connects to an AC adapter.
2 Ventilation slots Enable the computer to stay cool, even
after prolonged use.
3 External display
(VGA) port Connects to a display device
(e.g., external monitor, LCD projector).
4 Ethernet (RJ-45)
port Connects to an Ethernet 10/100/1000-based
network.
5 HDMI port Supports high definition digital video
connections.
6 USB 2.0 port Connect to USB 2.0 devices
(e.g., USB mouse, USB camera).
1
1 3 7 2 4 5 6
