AEC-AMC2-UL2 - Installation manual en 5
Bosch Sicherheitssysteme GmbH F.01U.097.253 | V 3.2 | 2010.01
Included parts
The metal housing inlcudes the following components:
Figure 1 Parts of the housing
1 = Cover grounding post
2 = Mounting rails for PS and AMC
3 = AMC grounding post
4 = Cable knock-outs for reader and signal cables
5 = Cover tamper switch
6 = Temperature sensor bracket
7 = Clips for rechargeable batteries
8 = Main grounding post
9 = AMC-EXT grounding post
10 = Power cable knock-outs
