1 SERVICE INFORMATION
1-1 Specifications
Dimensions Length* mm(in) 386 (15.2)
Width* mm(in) 223 (8.78)
Height mm(in) 258 (10.2)
Dry weight* kg(lb) 3.75 (8.27)
Engine Type KIORITZ, air-cooled, two-stroke, single cylinder
Two-piece casting, Ventilated piston
Rotation Clockwise as viewed from the output end
Displacement cm 3 (in 3 ) 34.0 (2.075)
Bore mm(in) 38.0 (1.496)
Stroke mm(in) 30.0 (1.181)
Compression ratio 6.5
Carburettor Type Diaphragm horizontal-draught
Supplier and Model Walbro WT-504
Venturi size-Throttle bore mm(in) 11.11 - 15.85 (7/16 - 5/8)
Ignition Type CDI (Capacitor discharge ignition) system
in a single integrated piece, with electronic timing advancer
Spark plug BPMR7A, RCJ7Y
Starter Type Automatic rewind
Rope diameter x length mm(in) 3.0 x 890 (0.12 x 35.0)
Fuel Type Premixed two-stroke fuel (Refer to operator's manual.)
Tank capacity cm 3 (U.S.fl.oz.) 320 (10.8)
Clutch Type Centrifugal, 3-shoe slide
Guide bar / Saw chain lubrication type Automatic with volume adjuster
Tank capacity, oil cm 3 (U.S.fl.oz.) 180 (6.09)
Sprocket Type Spur
Number of teeth 6
Pitch in 3/8 Low profile
Guide bar Type 30RC50-3/8 35RC50-3/8 40RC50-3/8
Called length cm 30 35 40
Gauge in 0.050
Saw chain Number of drive links 47 53 58
Pitch in 3/8 Low profile
Gauge in 0.050
2
SERVICE INFORMATION CS-3500
*Without guide bar and saw chain
